Chinese Howo TX Mixer Puming Truck Cost 25m 38m 42m 6X4 440HP Concrete Pump Truck

Chinese Howo TX Mixer Puming Truck Cost 25m 38m 42m 6X4 440HP Concrete Pump Truck
Chinese Howo TX Mixer Puming Truck Cost 25m 38m 42m 6X4 440HP Concrete Pump Truck Chinese Howo TX Mixer Puming Truck Cost 25m 38m 42m 6X4 440HP Concrete Pump Truck Chinese Howo TX Mixer Puming Truck Cost 25m 38m 42m 6X4 440HP Concrete Pump Truck Chinese Howo TX Mixer Puming Truck Cost 25m 38m 42m 6X4 440HP Concrete Pump Truck Chinese Howo TX Mixer Puming Truck Cost 25m 38m 42m 6X4 440HP Concrete Pump Truck Chinese Howo TX Mixer Puming Truck Cost 25m 38m 42m 6X4 440HP Concrete Pump Truck

Gambar besar :  Chinese Howo TX Mixer Puming Truck Cost 25m 38m 42m 6X4 440HP Concrete Pump Truck

Detail produk:
Tempat asal: Cina
Nama merek: sinotruk
Sertifikasi: iso ccc
Nomor model: bagaimana7
Syarat-syarat pembayaran & pengiriman:
Kuantitas min Order: 1
Kemasan rincian: Telanjang
Waktu pengiriman: 30 HARI
Syarat-syarat pembayaran: T/T, L/C
Menyediakan kemampuan: 200 unit minggu
Kontak

Chinese Howo TX Mixer Puming Truck Cost 25m 38m 42m 6X4 440HP Concrete Pump Truck

Deskripsi
Jenis daya: solar Max. Maks. vertical conveying distance jarak pengangkutan vertikal: 58 m
Max. Maks. horizontal conveying distance jarak pengangkutan horizontal: 34 m POIN PENJUALAN UNIK: Efisiensi operasi yang tinggi
Kapal tanker minyak: 400L
Menyoroti:

Chinese Howo TX concrete pump truck

,

6X4 440HP mixer pump truck

,

25m 38m 42m concrete pump

Chinese Howo TX Mixer Puming Truck Cost 25m 38m 42m 6X4 440HP Concrete Pump Truck



Concrete pump trucks are widely used in various construction scenarios, from residential buildings and commercial complexes to infrastructure projects like highways, tunnels, and dams. They are particularly valuable in projects where concrete needs to be placed in hard-to-reach areas, such as high-rise structures or narrow spaces, as the boom can be maneuvered with precision to deliver concrete exactly where it is needed.​
In summary, the concrete pump truck has revolutionized concrete placement in construction, offering mobility, precision, and efficiency that contribute to safer, faster, and more cost-effective building processes.



SINOTRUK HOWO A7 38M Mounted Concrete Pump Truck ZZ1257N4647P1
Cab
A7-W cabin, with one sleeper berth, with air conditioner
Engine
D10.38-40, 380hp, Euro 4 emission (Euro 2 emission engine is also available )
Transmission
HW19710T, 10F+2R speed, manual type, with HW70 PTO
Front axle
HF9 *1, 9 tons loading, drum type
Rear axle
HC16*2,32 tons loading, 4.8/5.73 speed ratio
Wheelbase
4600+1400mm
Steering
ZF steering, with power assistance
Bumper
High position, ,metal material
ABS:
Without ABS
Tire
12.00R20 radial tire, 11 pcs
Others
With cable PTO, BBM control module
Boom system
1. 38M CONCRETE PUMP TRUCK;
2. Max. Vertical height: 38M
3. Max. Horizontal Concrete Placing radius: 34M
4. Concrete placing depth: 25M
5. Control mode: Electric proportion
6. Folding type of boom:RZ type
7. Folding type of boom: 360°
8. Length of end hose : 3000MM
9. Concrete delivery pipe dia. :125
Pump system
1. Form of concrete distribution valve:S Valve
2. concrete cylinder: 230
3. Maximum feeding height: 1500 MM
4. Hopper capacity: 0.65 M3
5. Slump of pumped concrete: 160-220
6. Dimension of allowable maximum aggregate : 40MM



Chinese Howo TX Mixer Puming Truck Cost 25m 38m 42m 6X4 440HP Concrete Pump Truck 0Chinese Howo TX Mixer Puming Truck Cost 25m 38m 42m 6X4 440HP Concrete Pump Truck 1Chinese Howo TX Mixer Puming Truck Cost 25m 38m 42m 6X4 440HP Concrete Pump Truck 2Chinese Howo TX Mixer Puming Truck Cost 25m 38m 42m 6X4 440HP Concrete Pump Truck 3Chinese Howo TX Mixer Puming Truck Cost 25m 38m 42m 6X4 440HP Concrete Pump Truck 4



Chinese Howo TX Mixer Puming Truck Cost 25m 38m 42m 6X4 440HP Concrete Pump Truck 5

Chinese Howo TX Mixer Puming Truck Cost 25m 38m 42m 6X4 440HP Concrete Pump Truck 6

Chinese Howo TX Mixer Puming Truck Cost 25m 38m 42m 6X4 440HP Concrete Pump Truck 7

Mrs AnneHan (International Marketing depart)
E-Mail :AnneHan_Sinotruk@163.com

Cell &Whatsapp&Wechat: +86 18353169581
Linkin :AnneHan
Facebook:AnneHan

CHINA NATIONAL HEAVY DUTY TRUCK GROUP
JINAN HEAVY TRUCK IMPORT&EXPORT CO.,LTD


TRUCK ,TRAILER ,MACHINERY ,EQUIPMENT ,SPARE PARTS .....ETC FOR SALE&EXPORT .
